Stereo Signal Generator

Reference: Documentation

Features
Stacks Image 123
Multi-channel Output: It may be a stereo signal generator, but the left and right output signals can each be routed to up to 8 output channels.
Stacks Image 134
Multiple Independent Generators: 3 different noise generators, a sine-sweep (chirp) generator, and 2 periodic signal generators can all be operated independently, which means any combination of them can be included in each (left or right) output, simultaneously.
Specifications
  • Output: Up to 8 channels selectable for each of Left and Right output signals, selected from any available physical or virtual output channels
  • Amplitude Type: %, dB
  • Amplitude: Independent adjustment for each signal type
  • Pan: -100% to 100%, Independent adjustment for each signal type
  • Pan Type: Linear, Shelf
  • Polarity Inversion: Independently selectable for Left and Right output
  • Noise Generators
    • Random: White, Pink Filtering
    • MLS: White, Pink Filtering
      • Sequence Lengths: 31, 63, 127, 255, 511, 1023, 1047, 4095, 8191, 16383, 32767, 65535, 131071, 262143, 524287, 1048575
    • Pseudorandom: White, Pink Filtering
      • Sequence Lengths: 240, 256, 400, 480, 500, 512, 800, 960, 1000, 1024, 2000, 2048, 2400, 4000, 4096, 4800, 8000, 8192, 9600, 16384, 24000, 32768, 48000, 65536, 96000, 131072, 192000, 262144, 384000, 524288, 768000
  • Sweep Generator
    • Repeat: On/Off
    • Lower/Upper Frequency Limit
    • Duration
    • Duration Units: seconds, samples
    • Sweep Type: Linear, Logarithmic
    • Sweep Direction: Up, Down, Up then Down, Down then Up
    • Synthesis Domain: Time, Frequency
  • Periodic Signal Generator
    • Waveforms: Sinusoid, Rectangle, Triangle, Sawtooth
    • Simultaneous operation of 2 waveforms (A and B)
    • Frequency Range: 0 Hz (DC) to Nyquist
    • DC Offset: Independently adjustable for Left and Right output
  • Specifications Subject to Change
